[DIAGRAM(s) - top of page G8 of V 5.0 manual]
+
Hint: Make notes of which wires (colors, cables) you use for each connection, so
you will be able to keep track of which connection is which.
To construct your transceiver cable assembly, proceed as follows:
Wiring between your Transceiver Microphone and your KAM’98:
Follow the notes taken above and wire the cable assembly in the following order:
Step 1. Select the 5-wire microphone cable and the
DB-9 connector part from the cable assembly kit,
Step 2. Attach microphone cable wires to the following pins on
the DB-9 connector:
• pin 1 (transmit audio) — and make a note of
the color of the wire you used,
• pin 3 (Push-To-Talk) — and make a note of
the color of the wire you used, and
•
(for base and mobile units) pin 9 (ground for
microphone on radio) of the DB-9 connec
-
tor— and make a note of the color of the
wire you used.
+
Hint: You may find it easier to wire the male DB-9 connector if you first connect
it to the KAM’98 and use the KAM’98 as a “jig.” This may also keep the male
pins straight if you apply too much heat and soften the plastic in the male con
-
nector.
Step 3. Using a user-supplied microphone connector appropriate
for your transceiver and the notes taken above, attach
wires as follows:
Connect Your KAM’98 to Your Transceiver Installing Your KAM’98
KAM’98 v 8.3 59 User’s Guide
