KEB COMBILINE Z2 Series User Manual

14
PRODUCT DESCRIPTION
2 Product Description
ThisinstructionsforusedescribetheoutputltersoftheCOMBILINEZ2series.These
are consisting of a motor choke, a capacitor module and an appropriate cable set.
Component Material number
Z2 motor choke xxZ2F04-1003
Z2 capacitor module 00Z2G24-xxxx
Z2 cable set 00Z2T09-xxxx
The use of the motor choke is also possible on its own. It reduces the ripple of the motor
current and the dv/dt to protect the motor insulation.
Ifthecapacitorunitisconnecteddownstream,asine-wavelterisobtained.Thesine-
wavelteractsasalow-passlterfortheswitchingfrequencycomponentsofthedrive
converter output voltage and provides a sinusoidal voltage between the phases.
The components can be combined with each other in such a way that there is an optimal
solution for every application!
2.1 Specied application
Theoutputltersareintendedfortheinstallationintoelectricalsystemsormachines.
Technical data and information for connection conditions shall be taken from the name-
plate and from the instructions for use and must be strictly observed.
2.2 Unintended use
The operation of our products outside the indicated limit values of the technical data
leads to the loss of any liability claims.
