PRODUCT DESCRIPTION
2.3 Product features
ThisinstructionsforusedescribethecomponentsoftheZ2outputlters:
Device type: Outputlter
Series: COMBILINE Z2
Application range: 0...1600 Hz
TheCOMBILINEZ2outputltersarecharacterizedbythefollowingfeatures:
When using a motor choke
Reduction of the:
• rate of voltage rise (dv/dt)
• motor bearing currents
• motor losses
• motor noises
Whenusinganoutputlter
Sinusoidal output voltage, resulting in a reduction of:
• motor losses
• motor warming
• motor noises
• bearing currents
• EMC emitted interference
The structure itself is determined by:
• Low-loss winding strands as conductor material
• Core material specially designed for this frequency range
• Special capacitors for operation up to 800 / 1600 Hz
Thesefeaturesleadtoasignicantextensionofthemotorlifetime.
