DIMENSIONS AND WEIGHTS

3.3.9 Capacitor module with four power capacitors

110 110

315

370

270

310

340

360

Mounting direction

Material numbers 00Z2G24-00x4

Weight 22.5 kg

Dimensions All dimensions in mm

Figure 9: Dimensions and weight capacitor module with four power capacitors

CAUTION

Transport instructions

There is a risk of injury when lifting at the bus bar.

► Use only the recessed grips for transport.
