INSTALLATION AND CONNECTION

4.4.3 Connection of the motor chokes size 20 to 22

U1.1

U1.2

V1.1

V1.2

W1.1

W1.2

Legend

PE Protective earth connection

U1.1, V1.1, W1.1 Input motor choke

U1.2, V1.2, W1.2 Output motor choke

Figure 14: Connection of the motor chokes size 20 to 22
