KEB COMBILINE Z2 Series User Manual

20
DEVICE DATA
3.2.3 Mechanical data of the capacitor modules
Material number
Connection Tightening torque in Nm / lb inch
L1, L2 (N), L3 PE L1, L2 (N), L3 PE
00Z2G24-0005
Push-Lock
Terminal
3 x 10 mm²
Crimp connector
M4
— 2.5 / 21.1
00Z2G24-0015
00Z2G24-0025
00Z2G24-0035
00Z2G24-0045
00Z2G24-0055
00Z2G24-0065
00Z2G24-0006
00Z2G24-0016
00Z2G24-0007
00Z2G24-0017
00Z2G24-0027
00Z2G24-0037
00Z2G24-0047
00Z2G24-0057
00Z2G24-0051
3 x M12 bolt
Crimp connector
M6
10 / 88.5 8 / 70.8
00Z2G24-0061
00Z2G24-0001
00Z2G24-0011
00Z2G24-0021
00Z2G24-0031
00Z2G24-0002
3 x FlatAL 80x2 mm
drilling: ⌀ = 13mm
Crimp connector
M6
25 / 221 8 / 70.8
00Z2G24-0012
00Z2G24-0022
00Z2G24-0032
00Z2G24-0041
00Z2G24-0003
00Z2G24-0042
00Z2G24-0052
00Z2G24-0053
00Z2G24-0013
00Z2G24-0004
00Z2G24-0062
00Z2G24-0023
00Z2G24-0033
00Z2G24-0043
00Z2G24-0014
Table 7: Mechanical data of the capacitor modules
All data are rated values except minimum and maximum values.
