DIMENSIONS AND WEIGHTS

3.3.6 Capacitor module with a power capacitor

315

120

160

360

340

105

Mounting direction

Material number 00Z2G24-00x1

Weight 5.6 kg

Dimensions All dimensions in mm

Figure 6: Dimensions and weight capacitor module with a power capacitor

CAUTION

Transport instructions

► Use only the recessed grips for transport.
