INSTALLATION AND CONNECTION

4.4.2 Connection of the motor chokes size 13 to 19

Legend

PE Protective earth connection

U1.1, V1.1, W1.1 Input motor choke

U1.2, V1.2, W1.2 Output motor choke

Figure 13: Connection of the motor chokes size 13 to 19
