KEB COMBILINE Z2 Series User Manual

23
DEVICE DATA
3.2.6 Possible combination of output lters
Size
Motor choke Capacitor modules and cable set
Cur-
rent
in A
Material
number
0...600 Hz
@ fs = 6 kHz
0...800 Hz
@ fs = 8 kHz
0...1000 Hz
@ fs = 10 kHz
0...1200 Hz
@ fs = 12 kHz
0...1600 Hz
@ fs = 16 kHz
07 2.6 07Z2F04-1003 —
00Z2G24-0006
(00Z2T09-0002)*
00Z2G24-0065
(00Z2T09-0002)*
00Z2G24-0055
(00Z2T09-0002)*
00Z2G24-0035
(00Z2T09-0002)*
09 4.1
09Z2F04-1003 —
00Z2G24-0016
(00Z2T09-0002)*
00Z2G24-0007
(00Z2T09-0002)*
00Z2G24-0065
(00Z2T09-0002)*
00Z2G24-0055
(00Z2T09-0002)*
10 5.8
10Z2F04-1003 —
00Z2G24-0017
(00Z2T09-0002)*
00Z2G24-0007
(00Z2T09-0002)*
00Z2G24-0006
(00Z2T09-0002)*
00Z2G24-0055
(00Z2T09-0002)*
12 9.5
12Z2F04-1003 —
00Z2G24-0047
(00Z2T09-0002)*
00Z2G24-0037
(00Z2T09-0002)*
00Z2G24-0007
(00Z2T09-0002)*
00Z2G24-0006
(00Z2T09-0002)*
13 12
13Z2F04-1003 —
00Z2G24-0057
(00Z2T09-0002)*
00Z2G24-0047
(00Z2T09-0002)*
00Z2G24-0017
(00Z2T09-0002)*
00Z2G24-0006
(00Z2T09-0002)*
14 16.5
14Z2F04-1003 —
00Z2G24-0051
(00Z2T09-2010)*
00Z2G24-0057
(00Z2T09-0002)*
00Z2G24-0047
(00Z2T09-0002)*
00Z2G24-0016
(00Z2T09-0002)*
15 24
15Z2F04-1003 —
00Z2G24-0061
(00Z2T09-2010)*
00Z2G24-0051
(00Z2T09-2010)*
00Z2G24-0057
(00Z2T09-0002)*
00Z2G24-0017
(00Z2T09-0002)*
16 33
16Z2F04-1003 —
00Z2G24-0061
(00Z2T09-2010)*
00Z2G24-0061
(00Z2T09-2010)*
00Z2G24-0051
(00Z2T09-2010)*
00Z2G24-0037
(00Z2T09-0002)*
17 42
17Z2F04-1003 —
00Z2G24-0001
(00Z2T09-2010)*
00Z2G24-0061
(00Z2T09-2010)*
00Z2G24-0051
(00Z2T09-2010)*
00Z2G24-0047
(00Z2T09-0002)*
18 50
18Z2F04-1003 —
00Z2G24-0001
(00Z2T09-2010)*
00Z2G24-0001
(00Z2T09-2010)*
00Z2G24-0061
(00Z2T09-2010)*
00Z2G24-0057
(00Z2T09-0002)*
19 60
19Z2F04-1003 —
00Z2G24-0011
(00Z2T09-2010)*
00Z2G24-0001
(00Z2T09-2010)*
00Z2G24-0061
(00Z2T09-2010)*
00Z2G24-0051
(00Z2T09-2010)*
20 75
20Z2F04-1003 —
00Z2G24-0021
(00Z2T09-1010)*
00Z2G24-0001
(00Z2T09-1010)*
00Z2G24-0001
(00Z2T09-1010)*
00Z2G24-0051
(00Z2T09-1010)*
21 90
21Z2F04-1003 —
00Z2G24-0031
(00Z2T09-1010)*
00Z2G24-0011
(00Z2T09-1010)*
00Z2G24-0001
(00Z2T09-1010)*
00Z2G24-0051
(00Z2T09-1010)*
22 115
22Z2F04-1003 —
00Z2G24-0002
(00Z2T09-1010)*
00Z2G24-0021
(00Z2T09-1010)*
00Z2G24-0011
(00Z2T09-1010)*
00Z2G24-0061
(00Z2T09-1010)*
23 150
23Z2F04-1003
00Z2G24-0041
(00Z2T09-0025)*
00Z2G24-0002
(00Z2T09-1010)*
00Z2G24-0021
(00Z2T09-1010)*
00Z2G24-0011
(00Z2T09-1010)*
00Z2G24-0061
(00Z2T09-1010)*
24 180
24Z2F04-1003
00Z2G24-0042
(00Z2T09-0025)*
00Z2G24-0012
(00Z2T09-1025)*
00Z2G24-0031
(00Z2T09-1025)*
00Z2G24-0021
(00Z2T09-1010)*
00Z2G24-0001
(00Z2T09-1010)*
25 210
25Z2F04-1003
00Z2G24-0052
(00Z2T09-1035)*
00Z2G24-0022
(00Z2T09-1025)*
00Z2G24-0012
(00Z2T09-1025)*
00Z2G24-0021
(00Z2T09-1025)*
00Z2G24-0001
(00Z2T09-1010)*
26 250
26Z2F04-1003
00Z2G24-0062
(00Z2T09-0035)*
00Z2G24-0041
(00Z2T09-0025)*
00Z2G24-0012
(00Z2T09-0025)*
00Z2G24-0031
(00Z2T09-0025)*
00Z2G24-0001
(00Z2T09-0010)*
27 300
27Z2F04-1003
00Z2G24-0062
(00Z2T09-0070)*
00Z2G24-0041
(00Z2T09-0070)*
00Z2G24-0032
(00Z2T09-0035)*
00Z2G24-0012
(00Z2T09-0025)*
00Z2G24-0011
(00Z2T09-0010)*
continued on the next page
