29
DIMENSIONS AND WEIGHTS
3.3.5 Capacitor modules in housing
1)
111,4
106
237
252
5,5
30
15 222
65
Material number 00Z2G24-00x5, 00Z2G24-00x6, 00Z2G24-00x7
Weight 1.6 kg
Dimensions All dimensions in mm
Figure 5: Dimensions and weight of capacitor modules in housing
1)
Installation position variable.
