DIMENSIONS AND WEIGHTS

3.3.7 Capacitor module with two power capacitors

315

110 110

220

160

120

340

360

Mounting direction

Material number 00Z2G24-00x2

Weight 11.6 kg

Dimensions All dimensions in mm

Figure 7: Dimensions and weight capacitor module with two power capacitors

CAUTION

Transport instructions

There is a risk of injury when lifting at the bus bar.

► Use only the recessed grips for transport.
