DIMENSIONS AND WEIGHTS
3.3.8 Capacitor module with three power capacitors
110 110
13
25
315
3
3x
370
8
340
360
270
310
Mounting direction
Material numbers 00Z2G24-00x3
Weight 17.7 kg
Dimensions All dimensions in mm
Figure 8: Dimensions and weight capacitor module with three power capacitors
CAUTION
Transport instructions
There is a risk of injury when lifting at the bus bar.
► Use only the recessed grips for transport.
