KEB COMBILINE Z2 Series User Manual

48
INSTALLATION AND CONNECTION
4.7.4 Installation clearances for wall mounting for capacitors 00Z2G24-00x5, 00Z2G24-00x6, 00Z2G24-00x7
and motor chokes 07...12Z2F04-1003
Installation distances
Dimen-
sion
Distance in mm Distance in inch
A
B
D
E
F
C
D
A 150 6
B 150 6
C 150 6
D 150 6
E 0 0
F 150 6
Figure 24: Installation clearances for wall mounting
4.7.5 Installation clearances for oor mounting for capacitors 00Z2G24-00x1, 00Z2G24-00x2, 00Z2G24-
00x3, 00Z2G24-00x4 and motor chokes 13...30Z2F04-1003
Installation distances
Dimen-
sion
Distance in mm Distance in inch
A
B
D
E
F
C
D
A 100 4
B 0 0
C 100 4
D 100 4
E 100 4
F 100 4
Figure 25: Installation clearances for oor mounting
