PRODUCT DESCRIPTION
2.3 Product features
This instruction manual describes the power units of the following devices:
Unit type: Active Infeed Controller (AIC) / Charging module
Series: COMBIVERT H6
Power range: 11…173kVA/400V
Housing: B, C, E, G, P, S, U, W
The COMBIVERT H6 is characterized by the following features:
• System bus EtherCAT
1)
Transfer of setpoints and actual values between
control and AIC module.
• Error bus Channel 1: Error output of the connected DC buses
Channel 2: Charge condition of the DC link bus
• Diagnostic interface RS232/485interfacefortheconnectionofdisplays
or service tools.
• Inputs and outputs 4 digital inputs
4 digital outputs
• Separate supply Internal supply of the control unit and driver/power
unit are safe separated.
• Internal fuses The driver/power unit is connected via internal fuses
to the DC link bus.
• Cooling System universallybyatrearandairheatsink
1)
EtherCAT
®
is a registered trademark and patented technology, li-
censed by Beckho Automation GmbH, Germany.
2.3.1 Special features of the AIC module
• System bus EtherCAT Transfer of setpoints and actual values between
control and AIC module.
2.3.2 Particularities of the charging unit
• Temperature inputs Temperatureinputsforbrakingresistorandlter
monitoring
• Switch input Monitoring of the main contactor with auxiliary con-
tact
