KEB COMBIVERT H6 Series

3.3 DC link capacities of the H6 modules
Axis modules
Device size Capacity in µF
7/10/12singleaxismodule 195
7/10/
12 double axis module 195/195/390
13 280
14 390
15 560
16 705
18 1020
19 1360
20 1650
21 1950
22 2350
23 3100
24 3900
25 4700
Active Infeed Controller (AIC)
Device size Capacity in µF
14 390
19 1650
21 1950
23 3300
24 3900
26 5200
Table 9: DC link capacities of the H6 modules
30
DC LINK CAPACITIES OF THE H6 MODULES
