MECHANICAL INSTALLATION
3.4.8 Sine-wave EMC lter with DC regeneration
Alternatively, sine-wave EMC lters with DC regeneration and mains chokes can be
used.
Drive converter H6
Sine-wave
EMC lter
Mains chokes EMC lter IN / A Iin_max / A fS / kHz
14 0DZ1I05-1001 12Z1B04-1000 12E6T60-3000 9.5 16
8
14 0HZ1I05-1001 14Z1B04-1000 14E6T60-3000 16.5 26
19 / 21 0LZ1I05-1001 18Z1B04-1000 18E6T60-3000 50 75
19 / 21 0PZ1I05-1001 22Z1B04-1000 20E6T60-3000 60/90 108/162
24 0PZ1I05-1001 22Z1B04-1000 22E6T60-3000 115 175
24 0SZ1I05-1001 24Z1B04-1000 24E6T60-3000 180 270
4
23 0XZ1I05-1001 27Z1B04-1000 22E6T60-3000 145 290
26 0XZ1I05-1001 27Z1B04-1000 24E6T60-3000 200 378
26 0XZ1I05-1001 27Z1B04-1000 26U5A0U-3000 250 378
Table 11: Sine-wave EMC lter with DC regeneration
NOTICE
After an overload Iin_maxof60sapartialloadoperationof81%ofthe
rated current INismandatoryfor540s.
Further information can be found on the following link:
Installation Active Infeed Controller (AIC) with DC regener-
ationforsine-waveEMClter.
www.keb.de/leadmin/media/Manuals/dr/ma_dr_h6-afe-pu-
inst-20233091_en.pdf
Installationsine-waveEMClter.
www.keb.de/leadmin/media/Manuals/dr/ma_dr_z1-inst-sinus-emv-l-
ter_20146892_en.pdf
