6.1.6 Coolant heating depending on power loss and ow rate with water
0
1
2
3
4
5
0 1 2 3 4 5 P
D / kW
ΔT / K
100 l/min
50 l/min
40 l/min
30 l/min
20 l/min
10 l/min5 l/min
Figure 43: Coolant heating depending on power loss
6.1.7 Typically fall of pressure depending on the rate of ow
bar
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
0 5 10 15 20 25 30 35 40 45 50
l/mi
n
Figure 44: Typically fall of pressure depending on the rate of ow
71
COOLING SYSTEM
