KEB COMBIVERT H6 Series

Description Terminal Connections of the front side Terminal Description
+24Vbus X1C.1
X1C.3 +24Vbus
0 V X1C.2 X1C.4 0 V
DCbus+ X1D.1 X1D.3
DC bus (displayed
with protection against
contact for exterior
devices)
DC bus- X1D.2 X1D.4
Snap-in for front cover
Outputtothelter X1A
Figure 11: Connections of the front side
43
INSTALLATION AND CONNECTION
