Keithley 2002 Getting Started Manual

Table 5
Menu summary
Action Description
CONFIG-(function)
MENU
or
RANGE
▲
RANGE ▼
ENTER
EXIT
INFO
Press the CONFIG key, then a function key (e.g., DCV) to
view the top level of a function configuration menu.
Press the MENU key to view the top level of the main
menu. The operations that have no corresponding key are
included in the main menu.
Use the cursor keys to move the highlighted cursor among
menu selections, or the digits of a parameter value, or
change channels on the scanner.
Use the RANGE keys to increment and decrement digits of
a parameter value.
Accepts menu selection or data entry.
Cancels changes menu selection. Also returns you to the
previous menu level.
Displays context-sensitive information about the present
menu level. Toggles information message on/off.
Measurement Options 2-9

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
