:VOLTage:DC Path to conﬁgure DCV:

:NPLC <n> Set speed: 0.01 to 10 PLC.

:AUTO Enable or disable auto NPLC.

:RANGe Path to conﬁgure measurement range:

[:UPPer] <n> Specify expected reading to select range.

:AUTO <n> Enable or disable auto range.

:REFerence <n> Specify reference (rel): -1100 to +1100.

:STATe Enable or disable reference (rel).

:ACQuire Use input signal as reference (rel).

:DIGits <n> Specify measurement resolution (see note 1).

:AUTO Enable or disable auto resolution.

:AVERage Path to control the ﬁlter (see note 2).

[:STATe] Enable or disable the ﬁlter.

:TCONtrol <name> Select ﬁlter type (MOVing or REPeat).

:COUNt <n> Specify the ﬁlter count (1 to 100).

:AUTO Enable or disable auto ﬁlter.

:VOLTage:AC Path to conﬁgure ACV:

(DCV commands) The commands listed to conﬁgure DCV apply.

:COUPling <name> Specify input coupling: AC or DC.

:DETector Path to select AC type:

[:FUNCtion] <name> Select AC type: RMS, AVERage, PEAK, LFRMs,

NPEak or PPEak.

:PWINdow <n> Specify window in seconds (0.1 to 9.9) for NPEak

PPEak

:CURRent:DC

Path to conﬁgure DCI:

(DCV commands) The commands listed to conﬁgure DCV apply.

:METHod <name> Select measure technique: NORMal, ICIRcuit.

:CURRent:AC Path to conﬁgure ACI:

(DCV commands) The commands listed to conﬁgure DCV apply.

:COUPling <name> Specify input coupling: AC or DC.

:DETector Path to select AC type:

[:FUNCtion] <name> Select AC type: RMS or AVERage.

:RESistance Path to conﬁgure Ω2:

(DCV commands) The commands listed to conﬁgure DCV apply.

:OCOMpensated Enable or disable offset compensation.

:FRESistance Path to conﬁgure Ω4:

(DCV commands) The commands listed to conﬁgure DCV apply.

:OCOMpensated Enable or disable offset compensation.

IEEE-488 Bus Operation 3-13

Keithley 2002 Getting Started Manual
