Operation of the Rotary Harvesting Unit

ZX,686RHU013510 1901MAR991/1

Adjusting the Large Dividers

The working height of each large divider (A) can be

adjusted.

Loosen fixing screw (B) of adjusting strap (C), then set

divider (A) to the desired position.

Tighten screw (B).

ZX016565 —UN—26FEB99

3029

040810

PN=81
