Kemper 360 - Length­of­cut Adjustment with NEW HOLLAND and CASE Forage Harvester

Operation of the Rotary Harvesting Unit
KM00321,0000285 1922FEB104/4
Continued on next page KM00321,0000286 1922FEB101/3
Cutterhead with 24 knives (type 494)
Twospeed gear box (III) for short length of cut (option)
KM1001123 —UN—22FEB10
I—Length of cut, number of knives II—Lengthofcut
transmission, forage
harvester
III—Rotary harvesting
unit drive
IV—Gathering drum
speed
2x12 knives 2x6 knives
Gear Gear
rpm
4 mm 8 mm 2 41
5 mm
10 mm 2 41
6 mm 12 mm 2 41
7 mm
14 mm 2 41
8 mm 16 mm 1 51
9 mm 18 mm 1 51
10 mm 20 mm
1
1 51
11 mm 22 mm 2 1 51
LengthofCut Adjustment with NEW
HOLLAND and CASE Forage Harvester
IMPORTANT: On forage harvesters equipped with
infinitely variable lengthofcut adjustment
HYDROLOC the drum speed of the KEMPER
rotary harvesting unit must not exceed 65 rpm.
The relevant input speed at the drive case of
the rotary harvesting unit is 620 rpm max.
The lengthofcut shift lever (A) is located on the righthand
side next to the feed roll housing (seen in the direction
of travel).
When High (H) or Low (L) is shifted the drive speed of
the rotary harvesting unit will change accordingly (refer to
table below: Length of Cut and Drum Speeds with NEW
HOLLAND and CASE Forage Harvester).
KM1000890 —UN—08JUN09
A—Shift lever
3022
040810
