X8 MIG WELDER 2.5 Operation
2.5.2.2 Calibrating arc voltage
X8 MIG Welder measures the voltage of the welding arc and the voltage loss in the
interconnection cable and welding gun. After calibration, the power source calculates the arc
voltage, if the voltage sensing cable is not connected.
Figure 24: Calibration of the welding cables
Proceed as follows:
1.
Ensure that the measurement cable connects the wire feeder and the power source.
OPERATING MANUAL | EN 113
©
KEMPPI 2017 | 1817
