X8 MIG WELDER 2.5 Operation
4.
Select the target channel and press the green button.
When you save the welding parameters, the channel name changes to the program name.
5.
Modify the parameters.
6.
Save the modified parameters. See Saving modified memory channel settings on page 118.
Saving new welding programs
When you install new welding programs, you need to create a memory channel for each of them
before use.
Proceed as follows:
1.
Install the new welding programs as instructed.
The welding programs automatically transfer into the memory of the welding system.
Note: You can also transfer the welding programs through the power source USB
port, if a wireless connection is unavailable.
2.
Select the Channel view.
3.
Select a memory channel.
4.
Press the green button to open the Actions menu.
5.
Select Create all and press the green button.
Control Pad creates a memory channel to each new welding program.
OPERATING MANUAL | EN 121
©
KEMPPI 2017 | 1817
