X8 MIG WELDER 2.4 Installation
2.
Pull the release lever at the front of the wire feeder rotating plate, and turn the top sideways
to allow access to the bottom half.
3.
Attach the bottom of the wire feeder rotating plate to the power source with four screws (1)
and washers (2).
