X8 MIG WELDER 2.4 Installation
2
1
5 Nm
4.
With the control panel facing the same way as the power source front panel, place the wire
feeder in the corresponding grooves on the wire feeder rotating plate.
5.
Slide the wire feeder from front to back until the bar in the back of the unit locks to the
orange claw at the back of the wire feeder rotating plate.
2.4.3.2 Installing welding gun holder
Install the welding gun holder to either side of the wire feeder.
OPERATING MANUAL | EN 37
©
KEMPPI 2017 | 1817
