X8 MIG WELDER 2.4 Installation
1
2
1
2
Proceed as follows:
1.
Install the welding gun holder mount to the wire feeder with 2 screws going to the
corresponding holes on the wire feeder upper cover hinge.
2.
Attach the welding gun holder to the mount with 2 screws.
2.4.3.3 Replacing feed rolls
Replace the feed rolls when the material and diameter of the filler wire changes.
Proceed as follows:
1.
Open the top cover and lift the pressure handle.
OPERATING MANUAL | EN 38
©
KEMPPI 2017 | 1817
