X8 MIG WELDER 2.4 Installation
Wire feed rolls, plastic
1.0 W001067 W001068
1.2 W001069 W001070
Al (Fc, Mc,
Ss, Fe)
U-groove
1.6 W001071 W001072
Wire feed rolls, metal
Filler wire
material
Feed roll
profile
Filler wire
diameter
(mm)
Feed roll
identification
Drive roll
code
Pressure roll
code
0.8−0.9 W006074 W006075
1.0 W006076 W006077
1.2 W004754 W004753
Fe, Ss (Al,
Mc, Fc)
V-groove
1.4 W006078 W006079
1.0 W006080 W006081
1.2 W006082 W006083
1.4−1.6 W006084 W006085
Fc, Mc (Fe) V-groove,
knurled
2.0 W006086 W006087
1.0 W006088 W006089
1.2 W006090 W006091
Al (Fc, Mc,
Ss, Fe)
U-groove
1.6
See the text
on the roll
W006092 W006093
5.
Place the feed rolls back to their places. Align the cut on a drive roll's bottom with the pin on
the drive shaft.
