X8 MIG WELDER 2.4 Installation
6.
Reattach the mounting pins to lock the drive and pressure rolls to their places. Align one of
the cuts on the bottom of the pressure rolls' mounting pin with the stud on the mount.
7.
Lower the pressure handle on the feed rolls and close the top cover.
2.4.3.4 Replacing wire guides
The wire feed mechanism includes two wire guide tubes. Replace them when the filler wire
diameter grows or the material changes.
2
1
OPERATING MANUAL | EN 44
©
KEMPPI 2017 | 1817
