X8 MIG WELDER 2.4 Installation
1. Inlet tube
Pull out the inlet tube and insert a new one. There is no additional locking.
2. Middle tube
A metal piece locks the middle wire guide tube in its place. Turn the piece aside to free the
middle wire guide tube for replacement. Turn it back to lock down the new middle wire guide
tube.
2.4.3.5 Changing wire spool
Note:
Install the welding gun to the wire feeder before installing the wire spool.
Caution:
If you change the filler wire to a different diameter or material, change the feed rolls
accordingly.
Proceed as follows:
1.
Remove the wire spool.
1
2
7
6
5
3
4
a) Open the top cover latch (1).
b) Lift the top cover up (2).
c) Cut and file the tip of the filler wire (3).
OPERATING MANUAL | EN 45
©
KEMPPI 2017 | 1817
