X8 MIG WELDER 2.4 Installation
Note:
The sharp cut tip of the filler wire may cause damage to the wire liner, if not filed.
d) Press Wire retract to pull back the remaining filler wire from the welding gun (4).
e) Push the wire spool locking cover aside (5).
f) Lift the wire spool from the wire feeder (6).
g) Pull or screw the wire spool brake halves apart (7).
2.
Install a new wire spool.
4
2
1
3
a) Attach the wire spool brake halves to the new wire spool by pushing or screwing them
together inside the wire spool (1). Ensure that the wire spool brake is firmly attached to
the wire spool.
b) Open the top cover and push the wire spool locking cover aside (2).
c) Lower the wire spool to its socket (3).
Note:
OPERATING MANUAL | EN 46
©
KEMPPI 2017 | 1817
