X8 MIG WELDER 2.4 Installation
Note:
The control panel shows how much the filler wire has run.
m) Select the shielding gas and attach the gas cylinder to the wire feeder.
n) Press Gas test to flush the former shielding gas from the system.
Note:
You can also use this button to test that the gases flow through the system
properly.
o) Close the top cover.
Wire spools
A
C
B
X8 MIG Welder has three different wire spool hub options available for different wire spools:
A. Standard spool
B. Spool hub for the small wire spool
Attach the extension pieces to the standard spool halves with a screw.
C. Spool hub for the wire spool with a large center hole
OPERATING MANUAL | EN 49
©
KEMPPI 2017 | 1817
