X8 MIG WELDER 2.4 Installation
All parts are delivered with the wire feeder.
Pull the spool halves to detach them. There is also a screw in the center of the hub that you can
use.
2.4.3.6 Attaching interconnection cable to strain relief
To ease the installation of the interconnection cable and to prevent any unnecessary strain on the
cable connectors, attach both ends of the interconnection cable bundle to a strain relief.
Proceed as follows:
1.
Attach the strain relief holder to the transportation handle at the rear of the power source.
Fasten the strain relief holder with a bolt from below.
2.
Take the power source end of the interconnection cable and insert the strain relief pin to the
strain relief holder.
Note:
If the wire feeder is detached from the power source, insert the strain relief pin to the
holder from below.
Note:
If the wire feeder is on the power source, insert the strain relief pin to the holder
from above.
OPERATING MANUAL | EN 50
©
KEMPPI 2017 | 1817
