X8 MIG WELDER 2.4 Installation
6.
Assemble the cone (1), seal (2) and sleeve (3) (supplied with the new liner) over the liner
protruding from the welding gun connector. Tighten the sleeve as tight as possible with a
spanner.
1 2 3
7.
Cut the excessive liner (spiral liner with side cutting pliers, DL Chili liner with a carpet knife)
leaving 1 - 2 mm.
OPERATING MANUAL | EN 77
©
KEMPPI 2017 | 1817
