X8 MIG WELDER 2.4 Installation
3.
Screw in a new contact tip and tighten it with an appropriate tool. Some thread grooves on
the contact tip remain visible when the contact tip is properly connected to the gun.
Changing wire liner (water-cooled gun)
Caution:
Use the correct wire liner. The tip of the filler wire may damage an incorrect liner.
1.
Lay the welding gun cable straight on a flat surface.
OPERATING MANUAL | EN 81
©
KEMPPI 2017 | 1817
