X8 MIG WELDER 2.4 Installation
Changing contact tip (gas-cooled gun)
1.
Remove the contact tip.
2.
Replace the contact tip adapter / gas diffuser, if needed. Screw in and hand-tighten the new
adapter as tight as possible (no tool is needed). Make sure there is no gap between the
contact tip adapter and the black plastic bushing.
Note:
It is important to tighten the adapter properly to enable a tight connection of the
contact tip to the gun.
OPERATING MANUAL | EN 80
©
KEMPPI 2017 | 1817
