Kemppi X8 - Page 87

X8 MIG WELDER 2.4 Installation
Changing contact tip (water-cooled gun)
1.
Remove the gas nozzle and the contact tip.
2.
Replace the contact tip adapter (1) and gas diffuser (2), if needed. Screw in and tighten the
new adapter with a tool.
Note:
It is important to tighten the adapter properly to enable a tight connection of the
contact tip to the gun.
OPERATING MANUAL | EN 87
©
KEMPPI 2017 | 1817
