X8 MIG WELDER 2.4 Installation
1 2
3.
Screw in a new contact tip and tighten it properly with a tool.
2.4.6.3 Installing pistol grip handle
The pistol grip handle is suitable for all X8 MIG Guns. The handle improves the ergonomics of
many welding positions.
To attact the pistol grip handle, align the grooves and pull the handle forward to attach the front
side (1), and then push the handle back to snap-lock it into its place (2).
OPERATING MANUAL | EN 88
©
KEMPPI 2017 | 1817
