KERN ABS-N Series User Manual

ABS-N_ABJ-NM-BA-e-1715 11
3.2 Overview of displays
Display Description see chpt.
Battery symbol
Zero tracking function active
+
Chpt.12.1
Displays adjustment
+
Chpt. 8.2.1
Flashes prior to start of automatic adjustment, only models ABJ
+
Chpt. 8.1
Stability and reaction settings via „Easy Setting display“
+
Chpt.13.1
Balance is in dosing mode (pouring mode)
+
Chpt. 13.2
Balance is in formula mode
+
Chpt. 14.3
Menu lock active
+
Chpt. 11.5
Menu symbol
+
Chpt. 11.2
Auto Print function active
+
Chpt. 16.2.1
Not documented
Log menu settings
Tolerance marks in check weighing and target mode + Chpt. 15
The stability display indicates that the weighing value is stable.
Highlights current setting in the menu.
Negative weighed value
Stand-by mode
Ready for start formulation
Ready for start continuous data output („MANU ON“)
+
Chpt. 10.2
+ Chpt. 14.3
+
Chpt. 16.5.2
Indicates numeric value entry.
+
Chpt. 3.1.1
Shows the stored reference in piece number or percent determination mode.
+ Chpt.14.1
+
Chpt.14.2.3
Net weight in formula mode
+
Chpt. 14.3
Total weight (TOTAL) of all components in formula mode
+ Chpt. 14.3
Memory space piece weight
+
Chpt.14.1
Change position decimal dot for freely programmable weighing unit
+ Chpt.10.7.2
Balance is in piece counting mode
+
Chpt.14.1
Balance is in percent determination mode with user-defined reference weight + Chpt.14.2.1
Balance is in percent determination mode, reference weight =100%
+
Chpt.14.2.2
Units
Symbols
Numerical display/menu
