KERN ABS-N Series User Manual

ABS-N_ABJ-NM-BA-e-1715 75
16 Data output
The appliance interface allows a bi-directional data exchange from the balance to
external devices. This data exchange is asynchronous using ASCII - Code.
The following conditions must be met to provide successful communication between the
weighing balance and the printer.
• Use a suitable cable to connect the weighing balance to the interface of the
printer/PC.
Faultless operation requires an adequate KERN interface cable (optional).
• Communication parameters (baud rate, bits and parity) of balance and printer
must match.
16.1 Pin connection
Due to connection of an optional KERN interface cable the balance is equipped with a
RS232C interface.
Balance (RS-232C)
3 TXD
2 RXD
6 DSR
5 SG
4 DTR
7 CTS
8 RTS
