4. Data format 4 „DF.4“
Example 9.9949 g:
Position
Data
ASCII code
Explanation
1
S
53H
Stable weighing value = S (stable) 53H
Unstable weighing value = U (unstable) 55H
Positive weighing value = plus sign 2BH
Negative weighing value = minus sign 2DH
2
20H
3
20H
4
2BH
5
20H
Numeric weighing value is displayed in 8
positions.
Not required positions = space character 20H
Where necessary, Overload is displayed in 2
positions with O L
6
+
2BH
7
9
39H
8
.
2EH
9
9
39H
10
9
39H
11
4
34H
12
9
39H
13
20H
Weighing unit
14
20H
15
g
67H
16 C/R 0DH
Separator C/R = 0DH, L/F = 0AH
At CR+LF data length will be increased
Printout examples KERN YKB-01N
S +9.9949 g Stable/positive weighing value
U +9.9949 g Instable/positive weighing value
S -9.9949 g Stable/negative weighing value
U -9.9949 g Instable/negative weighing value
