Keyscan Inc. – Technical Guide (PC109x - 04.15)
Door Lock Hardware
Consult with the manufacturer's documentation for mounting door lock hardware.
The lock must be appropriate for the barrier and meet all applicable building codes and fire regulations. If
necessary, consult with local officials such as the fire department to ensure the installation conforms to
municipal, state, or provincial safety regulations. Permits may be required before installing magnetic locks.
Use a battery for temporary power to ensure the door operates properly – alignment, holding, activation, de-
activation – before connecting to the Keyscan access control unit.
Figure 16 – Typical Door Strike Connection
Figure 17 – Typical Magnetic Lock Connection
