Keyscan Inc. – Technical Guide (PC109x - 04.15)
Network Communication via Optional NETCOM2
The NETCOM2 is a modular serial to TCP/IP converter that can be connected via a RS-232 data cable to the
CIM board for network communication. The CIM circuit board with the network connection is referred to as CIM
0. This CIM unit must have a jumper on J4.
Important
The NETCOM2 must be programmed with the Keyscan NETCOM Program Tool utility in order to function.
Refer to the NETCOM2 Programming Guide for programming instructions.
Multiple Building Communication on a WAN
Keyscan requires a point-to-point private network where NETCOMs are used on a LAN/WAN (TCP/IP) that
integrates building-to-building communication for a non-reverse network application.
