Techn
ical Guide (PC10
9x - 04
.1
5)
61
Figure
42
–
Commu
nication - Dire
ct Serial
to Com Port on
PC with
Communication
Manager
GND
RS-232 (COM4)
Control Board
(PC 109x)
Green
Black
Brown & White not used.
Tape back separately.
Brown
Shield
Green
Black
Red
White
RS-232 5 conductor
22 AWG shielded cable
Maximum - 100 Ft (30 M)
TD
RD
DCD
DTR
CTS
Red
`
to ground lug
Shield*
Parts List
- RS-232 Data Cable
- Control Board
- PC (requires serial port)
IOCB (COM1)
RX
TX
Ensure S2
DIP switches 7 & 8
are OFF
KI-00153E-04-13
* Insulate shield with PVC tubing such as Alpha
(p/n PVC10516 16 AWG) or comparable
insulator.
