Keyscan CA4500B User Manual

Keyscan Inc. – Technical Guide (PC109x - 07.15)
116
Network Communication via Optional NETCOM2 Rev. B
The NETCOM2 Rev. B is a modular serial to TCP/IP converter that can be connected via a RS-232 data cable to
the CIM board for network communication. The CIM circuit board with the network connection is referred to as
CIM 0. This CIM unit must have a jumper on J4.
Important
The NETCOM2 must be programmed with the Keyscan NETCOM Program Tool utility in order to function.
Refer to the NETCOM2 Rev. B Programming Guide for programming instructions.
Multiple Building Communication on a WAN
Keyscan requires a point-to-point private network where NETCOMs integrate building-to-building
communication on a LAN/WAN (TCP/IP) for a non-reverse network application.

Keyscan CA4500B Specifications

General

Brand	Keyscan
Model	CA4500B
Category	Control Unit
Language	English
