Keyscan CA4500B User Manual

Keyscan Inc. – Technical Guide (PC109x - 07.15)
56
Exit Device Connections
A normally-open exit device contact unlocks its assigned door for its defined door relay unlock time and
overrides the alarm input during its defined door held open time. Examples of exit devices are exit push
buttons or motion sensors (PIR) etc.
Keyscan recommends a PIR with a pulse output of 1/2 second and suitable for its environment.
Figure 37 – Terminate Input Wiring – RTE Push Button
Single end of line
supervision
to Request
to Exit
to Common Return
Double end of line
supervision
Non-supervised
Notes
Diagram illustrates CA8500B. Connections also apply to
CA250B & CA4500B.
- CA250B – up to 2 Request To Exits
- CA4500B – up to 4 Request To Exits
- CA8500B – up to 8 Request To Exits
RTE
Push Button
COM
NO
NO = Normally Open
1K
3K
COM
NO
to Request
to Exit
to Common Return
1K
COM
NO
Cut View of CA8500B
Door Inputs - A RTE Inputs - B
8
76
54321
Common
8
76
54321
AUX Inputs - C
8
76
54321
Common Common AUX Inputs - D
16
1514
131211109
Common AUX Inputs - E
24
2322
2120191817
KI-00130E-10-13
Supervision level set in Client software:
System VII & Vantage – Site Unit Setup
Aurora – Hardware Setup
Supervision level applied to all door inputs, RTE inputs, and auxiliary inputs.
