Keyscan Inc. – Technical Guide (PC109x - 07.15)
Installation Notes on Proximity Readers
Do not run reader cables in the same conduit with AC power or signal cables. Keep reader cables at least 12
inches or 30 centimetres from AC, computer data, telephone data, or electric lock device cables. Do not install
readers within 3.5 feet or 1.1 metres of computer CRTs. Do not install readers where broad spectrum EMI
noise may be present. Motors, pumps, generators, and AC switching relays can create EMI noise. Readers
mounted on a metal surface can have reduced read ranges. See HID manual for operational details and
recommendations. The following diagrams illustrate HID readers with dual LEDs. On models 5365, 5395, and
6005 do not use the brown wire with "00" LED. If readers are single LED type "06", substitute the brown wire
in place of the orange wire.
S16 – 5 ON dual LED = 00
S16 – 5 OFF single LED = 06
C1 Beep
When the pre-alert wire is connected to C1 (Beep) on the reader terminal, the reader will also sound on
an “alarm tripped”.
To Next Page
