Calibration Procedures 4
Keysight 33210A Service Guide 93
3 Using the numeric keypad or knob, adjust the displayed voltage at each setup
to match the measured voltage. Select ENTER VALUE. (Entered values are
rounded to the nearest 100 μV).
4 After performing setup 28:
a If your calibration procedures require you to verify the adjustment just
made, exit the calibration menu and perform “AC Amplitude
(high-impedance) Verification” on page 69.
b If you are making all the adjustments and then verifying the instrument’s
performance, continue with the next procedure in this chapter.
20
[a]
-0.50 V Output of 0dB range
21 +0.15 V Output of -10dB range (Amplifier In)
22
[a]
-0.15 V Output of -10dB range (Amplifier In)
23 +0.50 V Output of 0dB range (Amplifier In)
24
[a]
-0.50 V Output of 0dB range (Amplifier In)
25 +1.5 V Output of +10dB range (Amplifier In)
26
[a]
-1.5 V Output of +10dB range (Amplifier In)
27 +5 V Output of +20dB range (Amplifier In)
28
[a]
-5 V Output of +20dB range (Amplifier In)
[a] Constants are stored after completing this setup.
Setup
Nominal Signal
DC level
