Keysight Technologies E5260 Series

Keysight E5260/E5270 Programming Guide, Edition 4 1- 33
Programming Basics
Data Output Format
A Measurement or source output data type. One bit.
B Data type. One bit.
C Measurement or output range. Five bits.
A Explanation
0 Source output data.
1 Measurement data.
B Explanation
0 Voltage data.
1 Current data.
C Explanation
01000 (8) 0.5 V or 1 pA range.
01001 (9) 5 V or 10 pA range.
01010 (10) 100 pA range.
01011 (11) 2 V or 1 nA range.
01100 (12) 20 V or 10 nA range.
01101 (13) 40 V or 100 nA range.
01110 (14) 100 V or 1 μA range.
01111 (15) 200 V or 10 μA range.
10000 (16) 100 μA range.
10001 (17) 1 mA range.
10010 (18) 10 mA range.
10011 (19) 100 mA range.
10100 (20) 1 A range for E5280B/E5290A HPSMU
or 200 mA range for E5291A MPSMU.
11111 (31) Invalid data is returned.
