Keysight Agile Signal Generator Service Guide 47
Troubleshooting
— If the signal generator does not meet the listed power level in Table 1-2,
proceed to “Troubleshooting the RF Path” on page 48.
The ALC loop circuitry is part of the A20 Output Leveling Module. It is likely an
unleveled or under power condition is the result of a problem with the A20
Output Leveling Module.
— For an N5193A signal generator, replace the A20 Output Leveling Module.
Table 1-2 Maximum Output Power
Maximum Output Power (Option 520/52E)
Frequency Standard Option AT1/AT2
Electronic Attenuator
Bypassed
Option AT1/AT2
Electronic Attenuator
Inline
10 MHz to 13 GHz +10 dBm +10 dBm −1 dBm
> 13 GHz to 18 GHz +10 dBm +10 dBm −4 dBm
>18 GHz to 20 GHz +10 dBm +10 dBm −6 dBm
Maximum Output Power (Option 540/54E)
Frequency Standard Option AT1/AT2
10 MHz to 13 GHz +10 dBm +8 dBm − 3 dBm
> 13 GHz to 18 GHz +10 dBm +8 dBm −6 dBm
> 18 GHz to 20.55 GHz +7 dBm +6 dBm −10 dBm
> 20.55 GHz to < 25.6 GHz +10 dBm +10 dBm −7 dBm
25.5 GHz to 32 GHz +7 dBm +6 dBm n/a
> 32 GHz to < 40 GHz +7 dBm +7 dBm n/a
